TB-1 Series Split Wall-Mounted Outdoor Public Drinking Fountain, Stainless Steel Touchless Infrared Sensor Water Dispenser
No.TB-1
Product Overview
This split wall-mounted public drinking fountain is suitable for scenic spots, parks, residential communities, plazas, hotels, office buildings and other outdoor public areas. The split structure simplifies wall mounting installation and facilitates later inspection and maintenance. The whole unit adopts stainless steel appearance, suitable for long-term outdoor use.
The machine can operate without electricity when equipped with 3-stage / 5-stage ultrafiltration filters. Power supply is required if you select compressor cooling module or infrared sensor water outlet function. RO reverse osmosis filtration system is not recommended for this model.
Dual Operation Modes: Power-free mode (only 3-stage / 5-stage ultrafiltration equipped, no power supply needed); Electric mode (power connection required if compressor cooling or infrared sensor water outlet is selected)
Filtration Configuration: Optional 3-stage / 5-stage ultrafiltration; RO reverse osmosis system is not recommended for this unit
Two Optional Compressor Cooling Technologies
Traditional compressor + cold water tank configuration: Cold water output 14L/H
Rapid circulation fast cooling technology: High-flow chilled water up to 40L/H
Main Material: Full stainless steel outer casing + food-grade stainless steel inner tank, wear-resistant, rust-proof and anti-corrosion
Water Inlet Mode: Direct tap water connection for quick and simple installation
Product Core Features
Thickened stainless steel body, sturdy and durable for long-term outdoor service
Waterproof and moisture-proof overall structure, adaptable to rainy and humid outdoor environments
Low power consumption for models equipped with cooling and infrared sensors, energy-saving and eco-friendly
Optional automatic infrared sensor water outlet, hygienic touch-free water access
Two compressor cooling systems available to match different water flow requirements
Flexible filter options: 3-stage or 5-stage ultrafiltration for selection
Split wall-mounted design saves floor space, perfect for public areas with limited space
Customization Support
Full OEM & ODM customization is available. We can adjust filter combinations, chilled water function, infrared sensor configuration, equipment dimensions, surface finish and brand logos as required, to satisfy customized demands of municipal construction, real estate supporting facilities, landscape and various engineering projects.
